2-Port Dual-Display DVI KVM Switch with USB 2.0 and Audio
Control two dual-DVI-monitor computers from one keyboard, mouse and pair of displays.
DADG-122
- Switches two dual-display computers using one keyboard, mouse and pair of DVI monitors.
- Single-link DVI video up to 1920x1200 at 60Hz (4:4:4) and 1920x1080 at 60Hz; HDCP 1.4 compliant.
- USB 2.0 hub function shares up to four peripherals, including keyboard and mouse, with a tracking system for independent device operation.
- 3.5mm stereo audio in and out, and a USB console.
- Front-panel button and hotkeys select the computer; a buzzer confirms switching.
- Auto scan intervals of 3, 8, 15 or 30 seconds.
- No drivers or software; plug-and-play keyboard and mouse on Windows and Mac hosts.
- Metal enclosure, DC 9-12V power, 58 x 160 x 100 mm and 731 g.
USB 2.0USB HIDHotkey ControlEDID ManagementHDCP 1.4
Overview
2-Port Dual-Display DVI KVM Switch with USB 2.0 and Audio
The DADG-122 shares a keyboard, mouse, two DVI monitors, USB 2.0 devices and stereo audio between two computers, each driving two displays. It needs no drivers or software and handles Windows and Mac hosts. It is built for dual-screen workstations that must be shared between two machines.
At a glance
- Category
- KVM Switches
- Video interface
- DVI
- Ports
- 2 ports
- Max. resolution
- 1920 x 1200 @ 60Hz (4:4:4)
- HDCP
- HDCP 1.4
Features
- Switches two dual-display computers using one keyboard, mouse and pair of DVI monitors.
- Single-link DVI video up to 1920x1200 at 60Hz (4:4:4) and 1920x1080 at 60Hz; HDCP 1.4 compliant.
- USB 2.0 hub function shares up to four peripherals, including keyboard and mouse, with a tracking system for independent device operation.
- 3.5mm stereo audio in and out, and a USB console.
- Front-panel button and hotkeys select the computer; a buzzer confirms switching.
- Auto scan intervals of 3, 8, 15 or 30 seconds.
- No drivers or software; plug-and-play keyboard and mouse on Windows and Mac hosts.
- Metal enclosure, DC 9-12V power, 58 x 160 x 100 mm and 731 g.
Specifications
| Model Name | DADG-122 |
|---|---|
| Computer/Server Ports (input) | DVI x 2 ( Dual Display x 2 PCs ) USB 2.0 Type B x 2 Audio Jack in x 2 Audio Jack out x 2 |
| Console Ports (output) | DVI x 2 ( Dual Display ) USB 2.0 Type A x 2 USB HID Type A x 2 Audio Jack in x 1 Audio Jack out x 1 |
| Video Resolution (Max.) | 1920 x 1200 @ 60Hz (4:4:4) 1920 x 1080 @ 60Hz (4:4:4) |
| Push Buttons | Port Selection x 1 |
| HDCP Compliance | HDCP 1.4 |
| Control Methods | Hotkey / Push Button |
| LED Indicator (Power / Status) | Computer ready x 2 (green) Computer selected x 2 (red) |
| Automatic scan interval | 3, 8, 15, 30 seconds |
| Power Supply | DC 9~12V |
| Operation Environment | 0~40°C, Humidity<80% |
| Storage Temperature | -20~60°C |
| Enclosure | Metal |
| H x W x D (mm) | 58 x 160 x 100 |
| Weight (g) | 731 |
Specifications are subject to change. Please confirm critical values with us before ordering.
Connection
