4K HDMI EDID Feeder with 2-Port Splitter and EDID Copy
HDMI EDID emulator and 1-to-2 splitter that keeps source video stable with 4K 30 Hz support.
VDDC-400HDMI
- Two-port HDMI splitter with one input and two outputs (main and aux), up to 4K at 30 Hz (4:4:4).
- Display emulation, or DDC ghost, mimics a display connected to the PC, player or console.
- EDID copy lets the unit copy or auto-learn EDIDs from connected displays.
- Stores multiple EDID sets: three for the main output and one for aux.
- Built-in EDID and HDCP engine maintains continuous video output; HDCP 1.4 compliant.
- Supports over 100 common resolutions.
- Works with any operating system; no software needed.
- Powered via 5 V DC Mini-USB.
4K@30HzEDID ManagementHDCP 1.4
Overview
4K HDMI EDID Feeder with 2-Port Splitter and EDID Copy
The VDDC-400HDMI splits one HDMI input to two outputs while emulating a connected display's EDID. It can copy or automatically learn EDIDs from attached displays and store them for recall. It fits installations where sources drop signal when displays are switched off or changed.
At a glance
- Category
- EDID, Boosters & Converters
- Video interface
- HDMI
- Max. resolution
- 3840x2160@30Hz ( 4:4:4 )
- HDCP
- HDCP 1.4
Features
- Two-port HDMI splitter with one input and two outputs (main and aux), up to 4K at 30 Hz (4:4:4).
- Display emulation, or DDC ghost, mimics a display connected to the PC, player or console.
- EDID copy lets the unit copy or auto-learn EDIDs from connected displays.
- Stores multiple EDID sets: three for the main output and one for aux.
- Built-in EDID and HDCP engine maintains continuous video output; HDCP 1.4 compliant.
- Supports over 100 common resolutions.
- Works with any operating system; no software needed.
- Powered via 5 V DC Mini-USB.
Specifications
| Model Name | VDDC-400HDMI |
|---|---|
| MAX. Video Resolution | 3840x2160@30Hz ( 4:4:4 ) |
| Video Input | HDMI x 1 |
| Video Output | HDMI x 2 (Main x 1, Aux x 1) |
| EDID Memories | Main HDMI x 3 Aux HDMI x 1 |
| Slide Switch | EDID Copy x 1 ( Main HDMI x 3 and Aux HDMI x 1 ) |
| Push Button | Copy x 1 |
| LED Indicator | Status x 2 |
| HDCP Compliance | HDCP 1.4 |
| Power Supply | DC 5V ( Mini-USB ) |
| Operating Environment | 0~40°C, Humidity<80% |
| Storage Temperature | -20~60°C |
| Enclosure | Metal |
| H x W x D (mm) | 24 x 98 x 64 |
| Weight (g) | 200 |
Specifications are subject to change. Please confirm critical values with us before ordering.
Connection
