4-Port VGA KVM Switch with USB 2.0 and Audio
Four-computer VGA KVM switch with a USB 2.0 hub and stereo audio sharing.
KAAG-114
- Four VGA computers share one keyboard, mouse, monitor and up to four USB 2.0 peripheral connections.
- Resolution up to 1920x1200 at 60Hz (4:4:4), covering UXGA and WUXGA, and 1920x1080 at 60Hz.
- A tracking system lets each USB device operate independently, avoiding duplicate peripherals.
- Stereo audio in and out, with a USB console for the keyboard and mouse.
- Front-panel buttons and hotkeys select the computer, and a buzzer confirms each switch.
- Auto scan at 3, 8, 15 or 30 seconds.
- Plug-and-play keyboard and mouse for Windows and Mac hosts, no drivers or software.
- Metal enclosure, DC 9-12V power, 44 x 220 x 130 mm.
USB 2.0USB HIDHotkey Control
Overview
4-Port VGA KVM Switch with USB 2.0 and Audio
The KAAG-114 shares a keyboard, mouse, VGA monitor, USB 2.0 devices and 3.5mm stereo audio among four computers. A front-panel button or keyboard hotkey changes the active computer. It works with Windows and Mac hosts without software, so it suits compact offices and test benches.
At a glance
- Category
- KVM Switches
- Video interface
- VGA
- Ports
- 4 ports
- Max. resolution
- 1920 x 1200 @ 60Hz (4:4:4)
Features
- Four VGA computers share one keyboard, mouse, monitor and up to four USB 2.0 peripheral connections.
- Resolution up to 1920x1200 at 60Hz (4:4:4), covering UXGA and WUXGA, and 1920x1080 at 60Hz.
- A tracking system lets each USB device operate independently, avoiding duplicate peripherals.
- Stereo audio in and out, with a USB console for the keyboard and mouse.
- Front-panel buttons and hotkeys select the computer, and a buzzer confirms each switch.
- Auto scan at 3, 8, 15 or 30 seconds.
- Plug-and-play keyboard and mouse for Windows and Mac hosts, no drivers or software.
- Metal enclosure, DC 9-12V power, 44 x 220 x 130 mm.
Specifications
| Model Name | KAAG-114 |
|---|---|
| Computer/Server Ports (input) | VGA x 4 ( Single Display x 4 PCs ) USB 2.0 Type B x 4 Audio Jack in x 4 Audio Jack out x 4 |
| Console Ports (output) | VGA x 1 ( Single Display ) USB 2.0 Type A x 2 USB HID Type A x 2 Audio Jack in x 1 Audio Jack out x 1 |
| Video Resolution (Max.) | 1920 x 1200 @ 60Hz (4:4:4) 1920 x 1080 @ 60Hz (4:4:4) |
| Push Buttons | Port Selection x 4 |
| Control Methods | Hotkey / Push Button |
| LED Indicator (Power / Status) | Power x 1 Computer ready x 4 (green) Computer selected x 4 (red) |
| Automatic scan interval | 3, 8, 15, 30 seconds |
| Power Supply | DC 9~12V |
| Operation Environment | 0~40°C, Humidity<80% |
| Storage Temperature | -20~60°C |
| Enclosure | Metal |
| H x W x D (mm) | 44 x 220 x 130 |
Specifications are subject to change. Please confirm critical values with us before ordering.
Connection
